                        Product Details:


 |
| Type: | Coating Production Line | Substrate: | Steel |
|---|---|---|---|
| Condition: | New | Machine Type: | Industrial Machine, Coating Equipment |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | PLC, Motor, Gear, Pump | Coating: | Powder Coating |
| Voltage: | 220V.380V | Power: | 50HZ |
| Dimension(L*W*H): | 67*47*66CM | Warranty: | 1 Year |
| Key Selling Points: | Competitive Price | Applicable Industries: | Construction Works |
| Showroom Location: | None | Weight (KG): | 28 |
| Product Name: | Paint Coating System | Usage: | Powder Coating Workpieces |
| Color: | Cutomized | ||
| Highlight: | steel ungrouped,steel manual powder coating gun | ||
HXC Electrostatic Spraying Technology:
Utilizes electrostatic principles to charge the sprayed powder, allowing it to adhere to the surface of the workpiece, thus improving coating uniformity and adhesion.
Efficient Powder Recovery:
Many electrostatic powder coating machines are equipped with powder recovery systems that effectively collect unused powder, reducing waste and lowering material costs.
Adjustable Parameters:
Supports adjustments for multiple parameters such as voltage, spray distance, and powder flow, allowing optimization based on different materials and working environments.
| Voltage | 110V/220V |
| Frenquency | 50/60HZ |
| input power | 50W |
| Max output current | 200ua |
| Output power voltage | 0-100kv |
| Input Air Pressure | 0.3-0.6Mpa |
| Output Air Pressure | 0-0.5Mpa |
| Powder consumption | Max 550g/min |
| Polarity | Negative |
| Gun weight | 480g |
| Length of gun cable | 5m |
